Features:

• High static pressure, energy-saving electronically commutated (EC) motor
• Energy efficiency up to 98%
• Standard summer bypass integration
• 15mm-20mm internal thermal and sound insulation
• Superlative performance
• Vertical and horizontal installation
• Maintenance panels on both sides
• Suitable for both left and right-hand installation
• Indoor temperature/ relative humidity sensors
• Optional integration of electric heaters
• Compact and handy design
• Compliance: EU1253/2014 ErP2016 ErP2018 EcoDesign
• Energy class A+
• according to EN12141-7

• Integrated management system
• HD 7-inch colour touch screen with real-time indoor air quality display
• Local demand management with variable speed
• Modbus RS485 smart house connection
• IAQ (Indoor Air Quality) sensors CO2/PM2.5/vOCs/TEMP/RH
• Proposed weekly operation
• Optional separate fan control
• Connection of multiple external CO2/RH/TEMP sensors
• Connection of multiple external boost switches
• Inlet/Fusion/IAQ automation
• Available with remote control
• Filter reverse reading/replacement notification
• Full settings on the control panel

• Type of ventilation motor: EC
• Max air flow(m3/h): 600@100Pa / 700@100Pa / 800@100Pa
• Max rated power: 230V-50Hz; 300W; 1.9A / 230V-50Hz; 330W; 2.4A / 230V-50Hz; 420W; 2.7A
• Power input range: 200-240 V; 50/60Hz
• Weight (kg): 120
• Filter: G4
• Power supply filter: G4, F8 (optional)
• Max static pressure (Pa): 250 / 310 / 430
• Type of heat exchanger: Counterflow
• Heat exchanger material: enthalpy
• Energy efficiency (%): 94-98 / 90-98 / 86-98
• Internal insulation material: polyethylene foam.
• Body material: coated steel sheet
• Temperature of transmitted air (C): -25 to +50
• Working environment temperature (C): +5 to +40
• Relative humidity of the working environment (%): below 80
• Connected air duct diameter (mm): 250
